Vacuum Pump Miniature Diaphragm 22D1180 Series Oilless to 26.3 LPM
Vacuum Pump Miniature Diaphragm 22D1180 Series Oilless to 26.3 LPM of Gast Manufacturing
Miniature Diaphragm 22D1180 Series
Shaded Pole Motor
20 psi continuous pressure (25 psi inter.)
22 inHg max. vacuum, 18.7 LPM open flow (60 Hz)
Miniature Diaphragm 22D1180 Series
Product Features
• Permanently lubricated ball bearings on rod and motor drive
bearing
• Rear sleeve bearing (DC 1002, 1005 models have ball bearing
for higher pressure)
• Field service capability
• PSC models include attached capacitor
• Includes AJ988 filter assembly, unattached
MATERIALS OF CONSTRUCTION
• Head assembly and bracket made of Polyphenylene Sulfide
(PPS) for excellent chemical and heat resistance
• Stainless steel valves
• Neoprene/nylon diaphragm standard
• Other diaphragm materials available
Product Specifications
| Motor | RPM | HP | kW | Thermal Protector | Net Wt. | ||
| 220-240/230-50/60-1 | 60 cycle | 50 cycle | 1 / 15 | 0,05 | • | Ibs. | kg |
| 3450 | 2850 | 8 | 3,6 | ||||
